EN 573 EN-AW-6060 T66 aluminum prifile 6005A
5.0
Material Aluminum alloy:
6063, 6061, 6005,6060, 6101
Temper:
T4,T5, T6
Section Shapes:
Square, rectangle ,round, and other complicated shapes by custom design.
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Surface treatment
1. Mill finished
2. Powder coating: Bronze, black, white, etc
3. Anodized: Black, silver, bronze, golden, champagne, etc
4. Wooden Grain Customized color tone is provided
Feature
1. Hight brightness and hardness
2. Strong coated adhesion
3. Anti-scratch, smoothness
4. High weather resistance ,high corrosion resistance ,good wear resistance
Standard Packaging
1. PE Protective film , PE shrink film for each bundle
2. Customized Packaging requirement
Certification
ISO9001:2015 / IATF16949:2016 /CE/ Other certificate which clients need
Quality Control
1. We operate the most strict quality control system, the detection is from
the material, production process
2. Die design →Die making →Extruding →Cutting →Heat Treatment→ QC →Surface treatment →QC →Packing →Shipping →After Sale Service
Product Parameters
Tensile Test:
Test Method :EN ISO 6892-1:2016
| Test item | Specimen type | Tensile strength (Rm)(MPa) | Proof strength (RPo.2)(MPa) | Elongation after fracture(A) L.=50mm (%) | Con. |
| Req. | ≥215 | ≥160 | ≥6 | ||
| Result | Rectangular specimen | 246 | 228 | 18.5 | Pass |
Note :The results comply with the requirement of EN755-2:2016 type 6060-T66.
| Aluminum Alloy Grade 6005-T5 | Involved in the product Aluminum profile | |||||||||
| Chemical Composition | Element | Si% | Fe% | Cu% | Mn% | Mg% | Cr% | Zn% | Ti% | Balance AL |
| Req. | 0.6-0.9 | ≤0.35 | ≤0.1 | ≤0.1 | 0.4-0.6 | ≤0.1 | ≤0.1 | ≤0.1 | ||
| Test Result | 0.651 | 0.1455 | 0.0101 | 0.0055 | 0.566 | 0.004 | 0.001 | 0.0205 | ||
| Mechanical Properties | Test item | Tensile Strength(Mpa) | Yeld Strength(Mpa) | Elongation(%) | Hardness(HW) | |||||
| Req. | ≥250 | ≥200 | ≥7 | >=14 | ||||||
| Test Result | 286 | 265 | 10 | 15 | ||||||
Product Packaging
木架1_看图王
木箱
铁框
Factory And Work Environment
工厂场景
会议
设备 (2)
检测
检测1
检测2
检测3
生产1
检测4
设备
生产2
生产3
Faq
1
What Is Custom Aluminum Extrusion?
Custom aluminum extrusion is a process of creating specific shapes and lengths of aluminum products based on a customer's design or requirements. This is achieved by heating up an aluminum extrusion billet and forcing it through a die or mold to create the desired shape.
2
What Are The Advantages Of Using Custom Aluminum Extrusion Profiles?
The advantages of using custom aluminum extrusion profiles include the ability to create unique and complex shapes, lightweight and strong material properties, excellent corrosion resistance, and high thermal conductivity. Additionally, these profiles can be produced in high volumes at a relatively low cost, making them ideal for mass production applications.
3
What Types Of Applications Are Custom Aluminum Extrusion Profiles Used For?
Custom aluminum extrusion profiles can be used for a wide range of applications, including construction, transportation, aerospace, electronics, industrial machinery, and consumer goods. They are commonly used for creating frames, enclosures, panels, railings, and other structural components.
4
What Are The Available Finishes For Custom Aluminum Extrusion Profiles?
The available finishes for custom aluminum extrusion profiles include anodizing, powder coating, painting, and polishing. These finishes can enhance the appearance, durability, and performance of the aluminum profile, providing a high-quality finish.
5
What Is The Typical Lead Time For Custom Aluminum Extrusion Profiles?
The typical lead time for custom aluminum extrusion profiles varies depending on the complexity of the design, the order quantity, and the availability of raw materials. Typically, lead times can range from several weeks to a few months. However, some aluminum extrusion manufacturers may offer expedited services to reduce lead time.
6
What Is An Aluminum Extrusion Supplier?
An aluminum extrusion supplier is a company that specializes in producing and supplying aluminum extrusion profiles and related products to commercial and industrial clients. These suppliers typically offer a wide range of sizes, shapes, and finishes to meet customer's specific requirements.
7
What Are The Benefits Of Using An Aluminum Extrusion Supplier?
The benefits of using an aluminum extrusion supplier include access to a wide range of high-quality aluminum extrusion products, reduced manufacturing costs, and faster production times. Additionally, suppliers can help customers with technical support, design, and development of customized products.
8
What Is The Difference Between Standard And Custom Aluminum Extrusions?
Standard aluminum extrusions are pre-designed profiles that are readily available in a range of sizes, shapes, and finishes. Custom aluminum extrusions are created based on a customer's specific design requirements and may involve complex shapes, special finishes, and other unique features.
9
How Do I Choose The Right Aluminum Extrusion Supplier?
The right aluminum extrusion supplier should have a track record of excellent quality and customer service, a wide range of products and capabilities, competitive pricing, and fast lead times. Additionally, they should be willing to work collaboratively with the customer to understand their needs and provide personalized solutions.
